When the ignition switch is turned "ON", battery voltage is applied from the battery to the PCM through the main relay. In case that the ignition switch is turned "OFF", the PCM is supplied with power through the battery power input line to control the basic operation of vehicle.
If the battery power input line has a problem, PCM sets P2507 and MIL(Malfunction Indication Lamp) turns on.
ITEM
Detecting Condition
Possible Cause
DTC Strategy
? Monitor the battery power input line
? Poor connection
? Open or short to ground in line
? Faulty PCM
Enable Condition
? -
Threshold value
Diagnosis Time
? Continuous(More than 5 sec.failure for every 10 sec.test)
MIL On Condition
? 1 driving cycle
