Once SJB receives right turn switch working signal, SJB makes right turn signal lamp flickering.
This code is set when Front right turn signal lamp circuit is shotted to ground for more than 150ms during right turn signal lamp operating.
Item
Detecting Condition
Possible Cause
DTC Strategy
Load Mornitoring
Poor connection
Short to ground in Front right turn signal lamp circuit
Faulty Front right turn signal lamp
Faulty SJB
Enable Conditions
IG KEY ON.
Threshold Value
It is abnormal if output voltage is 0V.
Diagnostic Time
Immediately
DTC Erasing Time
DTC is erased immediately after trouble fixed.
