The computer has one of the management functions that is the voltage supply to the sensors. The sensor supply voltage 2 is fed to the APS 2 and the RPS to be used to operate the sensors.
If the ECM is reading an uncharacteristic sensor supply voltage to the APS 2 and the RPS during two driving cycles, this code will be set.
DTC NO.
Detecting Condition
Possible Cause
C 001
C 002
? C 001
Sensor supply voltage < 4.7 V
? C 002
Sensor supply voltage > 5.2 V
? Engine Condition : IG ON
? Fuel Limit : YES
? Fuel Cut : NO
? EGR OFF : NO
? MIL : NO
? LIMP HOME MODE
Engine speed is fixed as 1200 rpm without the accel position sensor action.
? Open or short in circuit
? ECM
